Buy High-quality Crusher for excavator for sale Suppliers, Companies

Rotating Crusher is suitable for quickly and effectively removing crushed concrete such as beams, columns, and cement poles in buildings, while reducing noise and vibration.

The product has the following characteristics:

1. Using high-quality wear-resistant steel, with light weight and superior wear resistance;

2. Unique jaw tooth layout design, double-layer wear-resistant protection;

3. The structure has undergone load optimization design, balancing the opening size and crushing force.

4. Optional vertical car motor rotation system with 360 Â° rotation and brake function.

Send Inquiry

Product Description

Product Parameter

Item	Unit	HDFP-02	HDFP-04	HDFP-06	HDFP-08	HDFP-08S	HDFP-10
Excavator weight	ton	3-5	6-9	10-15	15-25	20-30	30-36
Max Open width A	mm	1032	1344	1723	2100	2100	2500
Height B	mm	420	600	750	850	900	1020
Width C	mm	75	95	112	180	180	360
Crushing Force (Middle)	KN	260	510	650	1170	1170	1500
Crushing Force (End)	KN	170	260	470	994	994	1350
Working pressure	Mpa	24	24	31	32	32	32
Hydraulic Flow	Lpm	80-120	100-140	120-180	180-250	180-250	200-300
Weight	kg	270	480	880	1600	1980	2500

Product Description

Rotating Crusher is suitable for quickly and effectively removing crushed concrete such as beams, columns, and cement poles in buildings, while reducing noise and vibration.

Hydraulic crushing pliers are a type of front-end accessory of excavators, which can break concrete blocks, columns, etc., cut and collect the steel bars inside. They are widely used in the demolition, steel bar recycling, concrete crushing, etc. Its work efficiency is two to three times that of a crushing hammer.

The R&D team has added a 360 degree rotation function to the crushing pliers, improving the maneuverability and accuracy of accurate operation, suitable for the initial dismantling of floor slabs at different angles and directions. In addition, the teeth on the crushing pliers are designed as replaceable parts for easy maintenance, reducing long-term costs.

Improve maneuverability: Add a 360° rotation support system, allowing the machine to rotate freely for accurate operations.

Easy Maintenance: Customized teeth and blades allow individual or complete replacement, saving time and maintenance costs.

High-Altitude Operation: Specifically designed for building demolition at heights due to superior maneuverability.

Silent Operation: Engineered to reduce noise and vibration during concrete crushing and steel cutting.

High Efficiency: Equipped with an acceleration valve for fast jaw movement, improving work speed significantly.

Durable Construction: Made from high-strength wear-resistant boards and imported blades for long service life.

Technical Features

✔

Using high-quality wear-resistant steel with light weight and superior durability.

✔

Unique jaw tooth layout design with double-layer wear-resistant protection.

✔

Load-optimized structure balancing opening size and maximum crushing force.

✔

Optional vertical motor rotation system with integrated brake function.

Frequently Asked Questions

What are the primary applications of a rotating crusher?

It is primarily used for demolishing reinforced concrete structures like beams, columns, and floor slabs, as well as recycling steel bars and crushing concrete blocks.

How does the 360-degree rotation benefit the operation?

The 360° rotation allows the operator to approach concrete structures from any angle, which is critical for high-altitude demolition and precise dismantling of floor slabs.

Are the wear parts of the crusher replaceable?

Yes, the crushing pliers feature a replaceable tooth design. Individual teeth or the entire set can be replaced easily, which significantly reduces maintenance costs.

Does this machine work faster than a traditional crushing hammer?

Yes, the hydraulic crushing pliers are generally two to three times more efficient than a traditional crushing hammer for demolition and material separation tasks.

Is the equipment suitable for residential area demolition?

Absolutely. It is designed for silent operation, significantly reducing noise and vibration compared to impact tools, making it ideal for urban and residential projects.

What materials are used to ensure the durability of the crusher?

We use high-strength wear-resistant steel for the body and imported material blades for the scissors to ensure the equipment withstands heavy construction wear.
