OEM Eagle hydraulic shear for excavator for sale Supplier, Companies

Eagle hydraulic shear is suitable for demolition of steel structures, processing of scrap steel, car dismantling, aircraft dismantling, ship dismantling, etc.


The product has the following characteristics:

1. The overall structure is made of wear-resistant steel, which has good toughness and wear resistance;

2. The pin is made of alloy steel and has a built-in oil passage to ensure usability;

3. Equipped with a rotating motor, with large torque and fast speed;

4. The oil cylinder uses a honed tube, and the oil seal has strong sealing performance to ensure product service life and shearing force;

5. Hook angle design makes it easier to hook materials.

Product Description

Product Parameter
Item Unit Model
HD-06 HD-08 HD-10 HD-12 HD-14
Forearm installation ton 13-17 18-27 25-35 28-39 40-50
Main arm installation ton - 14-18 20-26 20-28 28-39
Working Pressure bar 250-300 250-300 300-320 320-350 320-350
Working Flow lpm 90-110 180-220 200-250 200-250 250-300
Weight kg 1100 2400 3100 3800 5200
Rotating Flow lpm 30-40 30-40 30-40 30-40 30-40
Rotating Pressure bar 90-100 100-115 100-115 100-115 100-115
Opening mm 375 590 650 630 810
Cutting Depth mm 395 580 660 720 840
Full Length mm 2100 2500 2900 3000 3700
Product Description

Eagle hydraulic shear is suitable for demolition of steel structures, processing of scrap steel, car dismantling, aircraft dismantling, ship dismantling, etc. The equipment has dozens of patents and has obtained ICAS certification, CE certification and ISO9001 quality management system certification.

We continuously break through and innovate in professional technology, pay attention to team management and business management, establish a comprehensive personnel management, quality management, safety management, and environmental management system, effectively ensure safety production and product production quality, and lay a solid foundation for timely and high-quality delivery of products.

Eagle hydraulic shear for excavator
Eagle hydraulic shear application
Key Features
01
Durability: The overall structure is made of wear-resistant steel, ensuring excellent toughness and high wear resistance.
02
Advanced Engineering: Pins are made of alloy steel with built-in oil passages for superior usability and maintenance.
03
High Performance: Equipped with a rotating motor providing large torque and fast operation speeds.
04
Strong Sealing: The oil cylinder utilizes a honed tube with high-performance oil seals to guarantee long service life and maximum shearing force.
05
Optimized Design: The hook angle design is specifically engineered to make hooking and handling materials easier.
Excavator hydraulic shear components
Hydraulic shear close up
Frequently Asked Questions
What applications is the Eagle hydraulic shear suitable for?
It is ideal for the demolition of steel structures, processing scrap steel, and dismantling cars, aircraft, and ships.
What certifications does the product carry?
The product has obtained ICAS certification, CE certification, and ISO9001 quality management system certification.
What materials are used in the construction of the shear?
The main structure is made of wear-resistant steel, while the pins are crafted from high-grade alloy steel.
Does the shear support rotation?
Yes, it is equipped with a high-torque rotating motor that allows for fast and efficient positioning.
What range of excavator sizes can use these shears?
Depending on the model (HD-06 to HD-14), they can be installed on excavators ranging from 13 to 50 tons.
How is the shearing force maintained over time?
Through the use of honed tubes in the oil cylinders and high-performance oil seals that ensure strong sealing and consistent pressure.
