📊 Product Parameters
| Item |
Unit |
HDCP-01 |
HDCP-02 |
HDCP-04 |
HDCP-06 |
HDCP-08 |
HDCP-10 |
| Length A (mm) |
mm |
800 |
900 |
900 |
1160 |
1300 |
1500 |
| Height B (mm) |
mm |
435 |
530 |
530 |
650 |
720 |
730 |
| Width C (mm) |
mm |
442 |
550 |
550 |
700 |
900 |
1000 |
| Hit Force / Impulse force |
ton |
3 |
4 |
4 |
6.5 |
11 |
15 |
| Vibration Frequency |
rpm/min |
2000 |
2000 |
2000 |
2000 |
2200 |
2200 |
| Oil flow |
l/min |
30-60 |
45-85 |
45-85 |
85-105 |
120-170 |
120-170 |
| Operating pressure |
kg/cm² |
100-130 |
100-130 |
100-130 |
100-150 |
150-200 |
150-200 |
| Strike Area/Bottom measurement |
mm |
800*442 |
900*550 |
900*550 |
1160*700 |
1300*900 |
1500*1000 |
| Excavator weight |
ton |
2-4 |
4-6 |
6-10 |
12-16 |
18-24 |
30-40 |
| Weight |
kg |
200 |
350-500 |
350-500 |
650-800 |
900-1000 |
1100-1300 |
📝 Product Description
Hydraulic Compactor is suitable for the leveling of highway railway slope protection and road surface, as well as the leveling of construction sites and factory floors. As a professional manufacturer, all products have undergone quality control throughout the entire process from accessory procurement to product delivery, and have obtained ISO9001 quality management system certification and CE certification. The product has the characteristics of high strength, corrosion resistance, good toughness, low noise, safety and reliability. The product quality is excellent, trustworthy and reliable to choose with confidence!
We focus on team management and business management, establishing a comprehensive system for personnel management, quality management, safety management, and environmental management, effectively ensuring safety production and product quality, and laying a solid foundation for timely and high-quality delivery of products.
⭐ Key Features
1
Simple structure, convenient operation, and easy maintenance and use.
2
The split type shelving link structure can adapt to various excavators.
3
Adopting a side standing shock absorber design, the structure is compact and the excitation force is greater.
4
High quality steel, alloy steel shaft, sturdy and durable for long-term industrial use.
Frequently Asked Questions
What are the primary applications for this hydraulic compactor?
It is ideal for leveling highway and railway slope protection, road surfaces, construction sites, and factory floors where high-density compaction is required.
Can this attachment fit different brands of excavators?
Yes, it features a split-type shelving link structure designed to adapt easily to various excavator models and brands.
What certifications do your hydraulic compactors hold?
All products are manufactured under strict quality control and have obtained both ISO9001 quality management system certification and CE certification.
How does the side-standing shock absorber design benefit the user?
This design makes the structure more compact while providing a significantly greater excitation force, leading to more efficient compaction performance.
Is the maintenance process complicated?
No, the equipment is designed with a simple structure specifically to ensure convenient operation and easy daily maintenance for the user.
What materials are used in the construction of the compactor?
We use high-quality steel and alloy steel shafts to ensure the equipment is sturdy, corrosion-resistant, and durable enough for heavy-duty environments.
