OEM high-quality Tillt Coupler for excavator for sale

Tillt Coupler is suitable for excavators weighing 0.8-25 tons

The product has the following characteristics:

1. Using high-quality steel, with high strength and wear resistance;

2. The pin shaft is made of alloy steel, which has high strength and good toughness;

3. The oil cylinder adopts honing tube and high-quality oil seal, with short working cycle and long service life;

4. The rotator is lightweight and has a long lifespan;

5. Accurate positioning design for secure sales, ensuring safety and reliability.

Send Inquiry

Product Description

📋

Product Parameters

Item	Unit	HDTC-00	HDTC-00s	HDTC-01	HDTC-02	HDTC-04	HDTC-06	HDTC-06s	HDTC-08	HDTC-09	HDTC-10
Tilt Degree	°	180°	180°	180°	180°	180°	180°	180°	140°	140°	140°
Drive Torque	NM	927	1630	1630	4400	7190	10623	14688	18680	24987	43000
Tilt Working Pressure	bar	210	210	210	210	210	210	210	210	210	210
Tilt Necessary Flow	lpm	2-4	5-16	5-16	5-16	15-44	19-58	19-58	35-105	35-105	35-105
Quick Coupler Working Pressure	bar	25-200	25-200	25-200	25-200	25-200	25-200	25-200	25-200	25-200	25-200
Necessary Flow	lpm	15-25	15-25	15-25	15-25	15-25	15-25	15-25	20-30	20-30	20-30
Pin Spread Range	mm	125-150	160-185	195-235	235-280	256-330	340-420	/	410-490	460-585	465-590
Lift Point Capacity	kg	500	500	500	500	500	1000	/	1000	2000	2000
Hitch lift capacity	kg	1000	1600	2000	2000	3000	5000	/	8000	12000	12000
Suitable Excavator Weight	ton	1-1.9	2-2.9	3-3.9	4-5.9	6-9.9	10-14.9	15-17.9	18-23.9	24-29.9	30-36.9
Pin reference diameter	mm	20-30	30-35	35-40	40-45	50-55	60-65	70-80	80	90	90-100
Weight	kg	63	77	90	160	210	410	/	630	950	1250

📝

Product Description

The Tilt Coupler is suitable for excavators weighing 0.8-25 tons. It is designed for high-tech assisted rapid operations with different angle requirements, offering high flexibility and a wide range of applications. Made of high-quality steel with high strength and wear resistance, the quality is guaranteed.

We focus strictly on supplier management and have established a series of management plans to ensure product quality at the source. Long-term and stable cooperative relationships have been established with well-known raw material and supporting companies to ensure product quality and project schedules. We can also undertake different OEM needs and customize suitable products for you with qualified output.

When extraction work presents variations where manual digging might be needed, the Tilt Coupler provides your excavator with maximum versatility. By fitting tool angles precisely, there is no need to constantly reposition the excavator or risk dumping the machine. This is an excellent way to transform your existing bucket into a high-performance tilt bucket.

⭐

Key Features

Using high-quality steel, with high strength and wear resistance;
The pin shaft is made of alloy steel, which has high strength and good toughness;
The oil cylinder adopts honing tube and high-quality oil seal, with short working cycle and long service life;
The rotator is lightweight and has a long lifespan;
Accurate positioning design for secure operation, ensuring safety and reliability.

❓

Frequently Asked Questions

What range of excavator weights is this Tilt Coupler suitable for?

The Tilt Coupler is designed to be compatible with a wide range of excavators, typically ranging from 0.8 to 36.9 tons depending on the specific model chosen (HDTC-00 to HDTC-10).

What is the maximum tilt angle available?

Most models in the series offer a full 180° tilt capability, while larger models like the HDTC-08 to HDTC-10 provide a 140° tilt angle for heavy-duty stability.

What materials are used in the manufacturing of the Tilt Coupler?

The coupler is constructed from high-quality, high-strength steel for wear resistance. The pin shafts are made from alloy steel to ensure maximum toughness and durability.

Does the Tilt Coupler support custom OEM requirements?

Yes, we can undertake various OEM needs and customize products to suit your specific excavator requirements and project goals.

How does the Tilt Coupler improve site safety?

It features an accurate positioning design and high-quality oil seals in the cylinders. It also allows the operator to adjust tool angles without constantly repositioning the machine, reducing the risk of machine instability.

What kind of maintenance can I expect for the hydraulic components?

The oil cylinder uses a honing tube and high-quality seals designed for a long service life and short working cycles, minimizing the need for frequent maintenance.
