OEM Hydraulic Gantry Shear for sale Companies, Company

Hydraulic Gantry Shear is suitable for pre compression and shear of various low-carbon scrap steel, scrapped automotive casings, metal structural components, etc.

The product has the following characteristics:

1. Install high-strength wear-resistant alloy steel plates in areas prone to wear and tear, effectively extending the service life of the equipment;

2. The shear slider guide rail and shear oil cylinder adopt automatic lubrication to prevent dry friction damage;

3. The intelligent control system provides optimal shear control and reduces the idle stroke of the shear cylinder;

4. The maximum cutting angle can reach 12 degrees, with strong cutting ability.

Send Inquiry

Product Description

Product Parameters

Maximum output (t/h)	Scissor width (mm)	Minimum opening (mm)	Shearing capacity (mm)			Shear frequency (times/min)	Silo size (mm)	Feeding form	Main motor
Maximum output (t/h)	Scissor width (mm)	Minimum opening (mm)	Round steel	Square steel	Steel plate	Shear frequency (times/min)	Silo size (mm)	Feeding form	Main motor
3-4	1300	370	Φ65	50×50	35×800	3~4	4000×1400×400	Chain pusher	2×30KW
6-10	1700	480	Φ90	80×80	50×1000	3~4	6000×1600×800	Chain pusher	2×45KW
8-12	1720	580	Φ120	100×100	55×1200	3~4	8000×1600×850	Chain pusher	3×45KW
12-15	1920	580	Φ140	120×120	60×1900	3~4	8000×2000×900	Chain pusher	5×45KW
15-20	2130	680	Φ160	140×140	70×1900	3	8000×2000×900	Chain pusher	5×45KW
18-23	2130	680	Φ180	150×150	80×1900	3	8000×2000×1200	Chain pusher	7×45KW
20-25	2130	680	Φ210	180×180	110×1900	3	10000×2500×1200	Chain pusher	8×45KW
24-30	2130	680	Φ225	200×200	130×1900	3	10000×2500×1200	Chain pusher	10×45KW
30-38	2130	680	Φ250	220×220	150×1900	3	10000×2500×1200	Chain pusher	12×45KW

Product Description

Hydraulic Gantry Shear is suitable for pre-compression and shear of various low-carbon scrap steel, scrapped automotive casings, metal structural components, etc. This equipment is specialized for scrap steel processing, automobile recycling, renewable resource utilization, environmental protection, and energy-saving operations.

Features

Install high-strength wear-resistant alloy steel plates in areas prone to wear and tear, effectively extending the service life of the equipment.

The shear slider guide rail and shear oil cylinder adopt automatic lubrication to prevent dry friction damage.

The intelligent control system provides optimal shear control and reduces the idle stroke of the shear cylinder.

The maximum cutting angle can reach 12 degrees, providing strong cutting ability for complex materials.

Frequently Asked Questions

What types of scrap metal can the Hydraulic Gantry Shear process?

It is ideal for low-carbon scrap steel, scrapped automotive casings, and various metal structural components.

How does the automatic lubrication system benefit the machine?

The system automatically lubricates the shear slider guide rails and oil cylinders, which prevents dry friction damage and reduces maintenance frequency.

What is the advantage of the 12-degree cutting angle?

A higher cutting angle provides superior shearing force and allows the machine to bite into and cut through thicker materials more effectively.

Does the machine include wear protection?

Yes, high-strength wear-resistant alloy steel plates are installed in high-impact areas to significantly extend the equipment's lifespan.

How is the shear efficiency optimized?

The intelligent control system manages the shearing process to minimize idle strokes, ensuring maximum productivity and energy saving.

What feeding forms are available for these models?

Most models utilize a chain pusher feeding system, which ensures a steady and controlled movement of materials into the shear.
