OEM Breaker/Hammer for excavators for sale

1 / 3

OEM Breaker/Hammer for excavators for sale

Breakers are suitable for applications in construction fields such as metallurgy, mining, railways, highways, and construction

Breakers are an important working tool for hydraulic excavators, which utilize the pressure oil provided by the pump station of the excavator or loader to more effectively clean floating stones and soil in rock crevices under the foundation of the building. It is used in conjunction with hydraulic excavators and other power engines, and can be widely used in construction fields or processes such as metallurgy, mining, railways, highways, and construction. It can also be used for mining, crushing, and dismantling hard objects such as rocks, reinforced concrete, cement pavements, old buildings, etc. It can also be used for specific operations such as riveting, rust removal, vibration, compaction, and pile driving by changing the drill rod, and has a wide range of uses.

Send Inquiry

Product Description

📊 Product Parameters

Model	Unit	HD400	HD450	HD530	HD680	HD750	HD850	HD1000	HD1350A	HD1400A	HD1500	HD1550	HD1650	HD1750	HD1850	HD1950
Suitable Excavator Weight	ton	0.8-2.5	1.2-3.0	2.5-4.5	4.0-7.0	6.0-9.0	7.0-14.0	11-16	18-26	18-26	27-35	28-35	30-40	36-40	40-55	45-60
Chisel Diameter	mm	Φ40	Φ45	Φ53	Φ68	Φ75	Φ85	Φ100	Φ135	Φ140	Φ150	Φ155	Φ165	Φ175	Φ185	Φ195
Operating weight (Side)	kg	70	90	120	250	380	510	765	1462	1795	2144	2413	2650	3788	4516	5213
Operating weight (Top)	kg	80	100	120	298	375	577	890	1515	1808	1972	2632	3065	3909	4703	5435
Operating weight (Box)	kg	90	126	152	295	375	571	861	1500	1801	2071	2555	2833	3991	4886	5610
Height	mm	1135	1213	1317	1620	1899	2161	2316	2813	2813	3063	3115	3275	3556	3852	3986
Required oil flow	l/min	15-30	20-40	25-50	40-70	50-90	60-100	80-110	130-150	120-180	160-180	200-240	220-260	260-280	260-300	280-310
Operating pressure	bar	90-120	90-120	90-120	110-140	120-150	130-160	150-170	160-180	160-180	160-180	160-180	180-200	220-260	240-280	240-300
Impact Rate	bpm	800-1400	700-1200	600-1100	500-900	400-800	400-800	350-700	350-600	350-500	300-450	300-450	200-350	200-350	200-250	180-200
Hose diameter	inch	1/2	1/2	1/2	1/2	1/2	3/4	3/4	1	1	1	1 1/4	1 1/4	1 1/4	1 1/4	1 1/4
Impact power	joule	200	300	300	650	700	1200	2847	3288	4270	5694	7117	9965	12812	16500	18500

📄 Product Description

As one of the leading Hydraulic Hammer manufacturers, we offer a full range of Hydraulic Hammers for excavators from 0.8-60 tonnes. They are suitable for all kinds of brands and models of excavators. Breakers, with their advantages of safety and efficiency, have been widely used in secondary crushing in mining areas, gradually replacing secondary blasting for large block crushing.

In mining operations, the application of hydraulic fracturing hammers under certain special limiting conditions presents unique advantages, especially in selective mining and non-blasting mining operations, making it a new type of mining method. Our crushing hammers feature excellent quality, long service life, low maintenance cost, and competitive pricing. We maintain strict supplier management and establish long-term stable cooperative relationships with major raw material providers to ensure project schedules and product quality at the source.

✅ Key Features

Easy to locate and control during operation.

More conducive to efficient excavation tasks.

Lighter weight design reducing the risk of broken drill rods.

❓ Frequently Asked Questions

What range of excavators are these hammers suitable for?

Our hydraulic hammers are designed for a wide range of excavators, spanning from 0.8 tons to 60 tons, covering mini-excavators to heavy-duty mining machines.

What are the primary applications for these hydraulic breakers?

They are widely used in secondary crushing in mining, selective mining, non-blasting operations, demolition, and various excavation projects.

How do I choose the correct model for my machine?

Selection is primarily based on your excavator's weight and required oil flow. Please refer to the "Suitable Excavator Weight" and "Required oil flow" rows in our parameter table.

What is the advantage of the Box Silenced (Box) type?

The Box type breaker (often called silenced type) offers lower noise levels during operation and provides better protection for the hammer's main body.

What makes these hammers durable for mining?

We use high-quality raw materials and strict manufacturing standards, ensuring a long service life and low maintenance costs even in high-intensity mining environments.

Are the hammers compatible with different excavator brands?

Yes, our hydraulic hammers are engineered to be compatible with all major brands and models of excavators worldwide.
